COS Series Coil COS08
- Home
- Products
- Hydraulic Accessories
- Hydraulic Valve Accessories
- COS Series Coil
- Specifications
- How to Order
Model Number | VOLTAGE (V) | RESISTANCE | HOLDING CURRENT (A) | Power (W) | ||
---|---|---|---|---|---|---|
SOURCE RATED | HZ | RANGE | ||||
COS08-D1 -* | DC12V | - | 10.9~13.2 | 8.7 | 1.7 | 17 |
COS08-D2 -* | DC24V | - | 21.8~26.4 | 3.2 | 0.9 | 17 |
- Above value based on temperature 30℃, electric voltage allowance 10%.
- Coil-COS08 series application for VSE, VSV series, VWE08.
