Back Valves RVC-06G
- Specifications
- How to Order
| Model Number | Maximum Pressure (bar) | Connetcing PT | Maximum Flow (lpm) | Weight (kg) | |
|---|---|---|---|---|---|
| RVC-03G | 315 (4500 psi) | 3/8" | 90 (23.78 gpm) | 7 (15.4 lbs) | |
| RVC-06G | 3/4" | 200 (52.84 gpm) | 11.2 (24.7 lbs) | ||
| RVG-10G | 1-1/4" | 400 (105.678 gpm) | 18.6 (41.0 lbs) | ||
| Fluid Type | ISO VG 32, 46, 68 | ||||
| Viscosity (cSt) | 10~400 (59~1854 SSU) | ||||
| Operating Temperature (°C) | -15~70 (-5~158°F) | ||||
| Contamination Level | ISO4406. 21/19/16 NAS1638,10 | ||||
- All screws with metric measure, if require inch measure, please contact us.
